Baja Designs XL Linkable Roof Mount Light Kit for Trucks, Jeeps & UTVs



The Baja Designs XL Linkable Roof Mount Light Kit is designed for truck, SUV, and UTV customers who want the finished appearance of a light bar with the aiming control of individual LED pods. Mounted at the roofline or upper windshield area, the system follows the vehicle profile more naturally than a rigid one-piece housing and creates a purposeful lighting upgrade without losing visual balance. Its modular construction is especially useful for builds that need broad coverage, long-range reach, and a clean installation in the same package.

The XL Linkable platform connects multiple Baja Designs XL lights through a shared linking structure while preserving independent control at each light. Each pod can be adjusted horizontally, and the system provides up to 45 degrees of vertical pitch adjustment within an individual light or across the complete assembly. This flexibility allows a straight layout for flat mounting profiles or an arced layout that better follows a bumper, roofline, or custom support.

The roofline or upper windshield area position adds a practical advantage because the elevated position gives the individual lights a clear path over the hood and allows the linked assembly to follow the roofline for broad terrain coverage. Mixed lens patterns can spread light through near, mid-range, and distance zones instead of concentrating every pod in one narrow direction. Customers can tune the assembly for technical trails, faster open terrain, overland travel, or work-site visibility while retaining a consistent visual line across the front of the vehicle.

Vehicle-specific roof systems commonly use 7XL or 8XL arrangements and may be offered with XL Sport or XL Pro lights. XL Sport and XL Pro versions provide distinct output levels, giving customers a choice between capable modular illumination and a higher-output arrangement for more demanding nighttime travel. The linked design also makes the beam easier to shape across the width of the vehicle because individual lights can be aimed after the brackets are fully secured.

Vehicle-specific kits pair the light assembly with application-matched brackets, wiring, protective rock guards, and installation hardware. A preload support is included where required to add stiffness across longer linked assemblies and reduce unwanted movement over rough terrain. The lights use rugged housings, hard-coated polycarbonate lenses, MoistureBlock weather protection, and 5000K white output on clear-lens versions for natural terrain recognition.

This combination of modular aiming, durable construction, and application-specific mounting gives customers a complete lighting system rather than a loose collection of parts. Whether customers are upgrading for open-trail travel, desert routes, overlanding, racing support, technical terrain, or wide nighttime coverage, the Baja Designs XL Linkable Roof Mount Light Kit delivers adjustable roof-level illumination across multiple driving zones. Now Available at LEER!



---



Features & Specifications

Product Type: Vehicle-specific modular roof LED light kit

Brand: Baja Designs

Series: XL Linkable

Light Options: XL Sport or XL Pro on supported kits

Common Light Counts: 7XL and 8XL, application dependent

Per-Light Output: 3,162 raw lumens for XL Sport and approximately 4,095 raw lumens for XL Pro

Adjustability: Up to 45 degrees of vertical pitch adjustment

Horizontal Aiming: Independent adjustment at each light

Layout: Straight or arced to follow the roofline

Lighting Zones: Mixed optics can illuminate zones 1-4

Mounting Location: Vehicle-specific roofline or upper windshield brackets

Functionality:

• Projects light from an elevated position for broad terrain awareness
• Allows each pod to be aimed for a smoother multi-zone beam
• Supports straight or arced layouts across different roof profiles
• Provides XL Sport and XL Pro output choices on supported kits
• Uses application-specific brackets for secure roof-level mounting
• Includes protective rock guards and a linked wiring arrangement
• Supports overland, trail, desert, racing, and work-oriented use



---



Available Options

The Baja Designs XL Linkable Roof Mount Light Kit is available in multiple light-count, output, and wiring configurations:

• 7XL Roof Kit - A wide modular arrangement commonly used on select UTV roof applications.
• 8XL Roof Kit - A full-width arrangement commonly used on truck and SUV roof or upper windshield applications.
• XL Sport - Uses 3,162-lumen XL Sport lights for capable coverage with lower total power demand.
• XL Pro - Uses higher-output XL Pro lights for customers who need additional reach and intensity.
• Toggle-Switch Harness - Provides an independent control arrangement on supported kits.
• Upfitter Harness - Connects to compatible factory auxiliary switch systems on supported applications.

Choose the light count specified for the supported roof, choose XL Sport for capable modular output or XL Pro for greater intensity, and choose the wiring option that matches the vehicle control system.



---



Why Choose

This product is ideal for customers who want roof-level coverage, individual beam control, and a complete vehicle-specific installation package.

• Elevated mounting improves visibility across open terrain
• Independent pod aiming creates a more controlled beam than a fixed bar
• Straight or arced layouts follow different roofline shapes
• Sport and Pro choices support different output and electrical priorities
• Vehicle-specific brackets provide cleaner alignment and support
• Preload support adds stiffness to longer linked assemblies
• Protective rock guards shield the lenses when the lights are off
• Pre-crimped wiring simplifies the linked electrical connections



---



What's Included

• XL Sport or XL Pro LED lights in the quantity specified by the selected kit
• XL Linkable connecting links and support structure
• Vehicle-specific roof mounting brackets
• Preload support where required by the kit
• Toggle-switch or upfitter wiring harness, depending on the selected configuration
• Black rock guards
• Required installation hardware

Note: Confirm included components before installation.



---



Installation Notes

• Confirm vehicle year, model, trim, roof configuration, factory roof-rack compatibility, output level, light count, and wiring option before installation.
• Roof-mounted lighting can increase wind noise, and bracket placement must preserve door, roof-panel, windshield, seal, and accessory clearance.
• Set the straight or arced layout before final tightening, then aim each light to create continuous coverage without excessive overlap.
• Route wiring through a protected and weather-sealed path using the installation method specified for the vehicle.

Buyer is responsible for use in accordance with applicable vehicle, road, off-road, towing, racing, and local laws.



---



Warranty Information

Baja Designs lighting products are backed by a limited lifetime warranty against manufacturing defects and a 30-day satisfaction guarantee. Warranty service may require proof of purchase and review of the product condition before a claim is approved.

Coverage typically excludes improper installation, misuse, unauthorized modification, electrical damage, tampering, impact damage outside the warranty terms, and operation that does not follow the product instructions. Customers should retain purchase records and follow the installed kit instructions for wiring, mounting, aiming, maintenance, and service.
