How to Install the BEDSLIDE S Model

Feb 24 2026

The BEDSLIDE S Model delivers smooth sliding cargo access with a durable composite deck design, making it a practical and lightweight solution for work or adventure. This guide walks you through both assembly and installation to ensure a secure fit and long-lasting performance.

This blog is based on the official BEDSLIDE S Model Assembly and Installation Instructions.

Before You Start

Supplied Hardware (Assembly)

  • (8) 1/4"-20 x 1 1/4” elevator bolts
  • (8) 1/4"-20 serrated flange nuts
  • (2) 1/4"-20 x 1 1/4” button head bolts
  • (2) Fender washers
  • (2) 1/4"-20 nyloc nuts

Tools Required (Assembly)

  • 1/2”, 7/16”, and 9/16” wrenches
  • 5/32” Allen key
  • S series Rev 5

Supplied Hardware (Installation)

  • (4) 5/16" riv nuts
  • (1) Riv nut tool
  • (4) 5/16" x 2” hex head bolts
  • (4) 5/16" split lock washers
  • (4) 3/8" flat washers

Tools Required (Installation)

  • Drill
  • 1/2” drill bit
  • Sharpie
  • Tape measure
  • 1/2” socket & ratchet
  • 1/2” open-end wrench

Part 1: Assemble the BEDSLIDE S Model


Step 1: Bolt Down the Composite Deck

  • The deck halves ship upside down and resting on the BEDSLIDE frame.
  • Flip one half of the composite deck over.
  • Slide it under the center track.
  • Align the pre-drilled holes on the deck with the mounting holes on the frame.
  • Secure each deck half using:
    • (4) 1/4"-20 x 1 1/4” elevator bolts
    • (4) 1/4"-20 serrated flange nuts
    • Tighten all flange nuts using a 7/16” wrench
    • Repeat for the second deck half.

Step 2: Mount the Front BEDTRAX

  • Position the front BEDTRAX so its mounting holes align with the pre-drilled holes in the deck.
  • Secure using:
    • (2) 1/4"-20 x 1 1/4” button head bolts
    • Fender washers
    • Nyloc nuts
    • Tighten using a 7/16” wrench and 5/32” Allen key

Your BEDSLIDE S assembly is now complete.


Part 2: Install the BEDSLIDE S in Your Truck


Step 1: Center the BEDSLIDE & Check Fitment

  • Place the assembled BEDSLIDE into your truck bed.
  • Center it between the wheel wells.
  • Leave 1½ inches of clearance between the bulkhead and the BEDSLIDE frame.
  • Confirm that the tailgate clears the unit when closed and that the tray does not contact the tailgate when extended.
  • If clearance is an issue or your truck has a step in the gate, you may need the Lift Block Kit (Part #FPLB1)

Step 2: Mark & Drill Mounting Holes

  • Slowly extend the upper tray from the closed position to avoid shifting placement.
  • Using the pre-punched holes in:
    • The cab-end cross member
    • The center cross member
    • Mark (4) mounting locations.
    • Drill (4) 1/2” holes, choosing the hole location that rests on the highest part of the truck bed floor

Step 3: Install Riv Nuts

  • Move the BEDSLIDE to access the drilled holes.
  • For each hole:
    • Insert a 5/16” bolt through the riv nut tool and thread into a riv nut.
    • Insert the assembly into the mounting hole.
    • Tighten while holding the riv nut tool steady with a wrench.
    • Ensure the riv nut sits flush as it compresses beneath the bed surface.
    • Do not over-tighten.
    • Do not use air impact tools
    • Repeat for all four mounting points.

Step 4: Bolt Down the BEDSLIDE

  • Reinstall the BEDSLIDE into the truck bed and align the mounting holes with the installed riv nuts.
  • Secure each location using:
    • 5/16" x 2” hex head bolts
    • Split lock washers
    • Flat washers
    • Tighten securely

Step 5: Remove Protective Film

  • Peel away the protective film from the tie-down rails.
  • If any lettering lifts with the film, reposition it and press firmly using a card or your hand to ensure proper adhesion

Installation Complete

Your BEDSLIDE S Model is now fully installed and ready to provide safe, convenient cargo access every time you open your tailgate.
