Bilstein SNS2 Series Shock Absorber



Bilstein SNS2 Series Shock Absorber is built for customers who need a serious motorsports damper rather than a basic replacement shock. The smooth-body steel layout is made for motorsports customers who need rebuildability, durable construction, and a damper that can be tuned around track demands. It is aimed at race builds, custom suspension packages, and demanding setups where damping control is a key part of how the vehicle puts power down and stays composed.

The design gives builders a durable foundation for dialing in ride control around track surface, chassis balance, tire package, and driver preference. The 46mm monotube design gives the shock a proven performance foundation, while the smooth body keeps the package straightforward for non-coilover applications. For customers working with dirt, asphalt, desert, or mixed competition environments, that control helps the suspension respond with more consistency as conditions change.

The zinc-plated steel body, steel body cap, and heim mounting layout give the SNS2 Series a practical structure for race teams that need strength, serviceability, and repeatable installation dimensions. The finish and body layout are designed to support repeated service work, setup changes, and careful tuning without turning the shock into a disposable component. That matters for customers who maintain their own race program or work with a suspension specialist.

Stroke choices range from 4.82 in through 8.78 in, with multiple compression and rebound valve codes in the range. Rather than forcing every build into one length or tune, the series gives customers a focused range of motorsports choices that can be matched around ride height, available travel, mounting points, and the type of control the chassis needs. The result is a shock absorber that can be planned as part of a complete suspension system.

SNS2 dampers are intended for motorsports applications where rules, chassis design, and suspension package requirements determine the correct length and tune. Customers should match the shock to the vehicle's suspension geometry, intended use, and sanctioning requirements before installation. Correct length, mount style, spring hardware, and tuning components are critical to getting the intended performance from this type of damper.

Whether customers are upgrading for circle-track setup, asphalt racing, dirt racing, or rebuildable steel-body shock control, the Bilstein SNS2 Series Shock Absorber delivers a durable 46mm monotube platform with race-ready serviceability. Now Available at LEER!



---



Features & Specifications

Product Type: Suspension shock absorber

Brand: Bilstein

Series: SNS2 Series

Body Design: Smooth body screw top non-coilover

Body Material: Steel

Internal Design: Monotube

Finish: Zinc plated

Piston Diameter: 46mm

Shaft Diameter: 14mm

Adjustable Damping: Non-adjustable

Functionality:

• Supports motorsports applications that require a steel-body shock absorber.
• Provides a rebuildable damper platform for teams that maintain and tune suspension components.
• Helps racers match shock length and valve behavior to track conditions and chassis balance.
• Works well for non-coilover layouts that need a smooth shock body.
• Uses heim mounts for precise articulation in race suspension mounting points.
• Allows customers to select from multiple stroke lengths for different chassis needs.
• Helps provide consistent damping response through Bilstein monotube technology.



---



Available Options

The Bilstein SNS2 Series Shock Absorber is available in multiple race setup choices:

• Short Stroke Versions -- Shorter stroke choices help customers package the shock in compact suspension layouts.
• Mid Stroke Versions -- Mid-length options work for common race chassis setups where balanced travel is needed.
• Long Stroke Versions -- Longer stroke choices support applications that need more suspension movement.
• Valve Code Choices -- Different compression and rebound codes help racers match the damper to track feel and chassis balance.

Choose shorter stroke versions for compact packaging, or choose longer stroke versions when the suspension layout needs more usable travel.



---



Why Choose

This product is ideal for customers who want a rebuildable steel-body monotube shock for motorsports suspension tuning.

• Steel construction supports customers working within race rules that call for steel-body dampers.
• The 46mm monotube format gives the shock a strong foundation for consistent performance.
• Multiple lengths help make the damper practical for a range of race chassis layouts.
• Heim mounts support clean articulation through suspension movement.
• The smooth-body design keeps the package simple for non-coilover use.
• Rebuildable construction helps reduce waste and supports ongoing race service work.
• Zinc plating adds a clean protective finish for demanding shop and track environments.



---



What's Included

• One Bilstein SNS2 Series shock absorber matched to the selected setup.

Note: Confirm included components before installation.



---



Installation Notes

• Confirm shock length, mounting width, and valve choice before installation.
• Confirm whether the application requires separate pistons, piston bands, or tuning components before assembly.
• Cycle the suspension through full travel to verify clearance and avoid bind.

Buyer is responsible for use in accordance with applicable vehicle, road, off-road, towing, racing, and local laws.



---



Warranty Information

Bilstein motorsport shock absorbers in this series are backed by Bilstein's applicable limited 90-day warranty for eligible North American purchases. Coverage generally applies to defects in materials or workmanship and depends on proper installation, appropriate use, and the terms of the warranty program.

Warranty coverage typically excludes misuse, improper installation, modifications, incorrect setup, overloading, racing damage outside warranty terms, impact damage, tampering, or non-compliant use. Proof of purchase may be required for warranty claims.
