Baja Designs Squadron 2.0 Flush Mount LED Auxiliary Light Pod



Baja Designs Squadron 2.0 Flush Mount LED Auxiliary Light Pod is designed for customers who want compact auxiliary lighting with a more integrated installed look. Instead of placing a pod on top of a surface-mounted bracket, the flush mount format helps tuck the light into panels, bumpers, trailers, and custom lighting locations when the mounting surface allows. It gives the build a cleaner profile while still delivering the compact output and beam control that define the Squadron 2.0 platform.

The flush mount pod uses the same modern Squadron 2.0 lighting approach with next-generation optics and controlled beam patterns. Customers can select Spot for longer reach, Driving/Combo for a balanced forward pattern, Wide Cornering for wider side coverage, or Work/Scene for close-range area lighting. Clear and Baja Amber lens choices allow the light to be matched to general nighttime driving, dust, rain, fog, or work-zone visibility needs.

Sport and Pro versions give the flush mount pod meaningful output choices. The Sport version produces 3,200 lumens at 30W, making it a strong match for compact lighting positions, multipoint lighting systems, and utility applications. The Pro version increases output to 5,921 lumens at 65W for customers who want more intensity from a low-profile mounting style.

Black and white housing choices help the light blend with the surrounding build or stand out with Baja Designs signature styling. The updated gasket, secure clip-in service components, selectable backlight, and 4-pin Deutsch-style connector support a more durable and more finished lighting package. The flush mount body is especially helpful when customers want to reduce visual bulk and protect the light from protruding farther than needed.

The compact 2.84 in. by 3.29 in. by 3.32 in. light size makes the Squadron 2.0 flush mount pod suitable for custom panels where packaging matters. Customers should verify panel depth, clearance, wiring access, and mounting surface strength before installation. Once mounted and aimed correctly, the pod can add purposeful light from a clean, built-in position.

Whether customers are upgrading for bumper-integrated lighting, work lighting, trail use, or a more finished custom build, the Squadron 2.0 Flush Mount LED Auxiliary Light Pod delivers compact Baja Designs performance in a low-profile format. Now Available at LEER!



---



Features & Specifications

Product Type: Flush mount LED auxiliary light pod

Brand: Baja Designs

Series: Squadron 2.0

Output Options: Sport: 3,200 lumens at 30W; Pro: 5,921 lumens at 65W

Beam Patterns: Spot, Driving/Combo, Wide Cornering, and Work/Scene

Lens Colors: Clear and Baja Amber

Housing Colors: Black and white

Dimensions: 2.84 in. length, 3.29 in. height, 3.32 in. depth

Water Resistance: IP69K rated

Functionality:

• Creates a cleaner auxiliary lighting install for bumpers, panels, trailers, and custom mounting panels.
• Supports long-distance, balanced, wide-angle, or close-range lighting depending on selected beam pattern.
• Helps reduce exposed bracket bulk when a recessed mounting location is preferred.
• Works well for front-facing, side-facing, rear-facing, utility, and work-zone lighting positions when installation allows.
• Offers Sport and Pro output choices for different electrical demand and brightness needs.
• Gives customers Clear and Baja Amber lens options for different weather, terrain, and visibility conditions.
• Combines compact size, sealed construction, and serviceable design features for demanding use.



---



Available Options

The Squadron 2.0 Flush Mount LED Auxiliary Light Pod is available in multiple configurations:

• Sport -- A 3,200-lumen, 30W flush mount version for strong compact lighting with efficient power use.
• Pro -- A 5,921-lumen, 65W flush mount version for customers who want higher output from a low-profile installation.
• Spot -- A beam pattern for longer-distance visibility when the mount position is aimed downrange.
• Driving/Combo -- A beam pattern that blends forward reach with a wider usable field.
• Wide Cornering -- A beam pattern for side fill, cornering, and technical trail visibility.
• Work/Scene -- A broad close-range beam for work areas, camp lighting, reverse lighting, and utility use.
• Clear or Baja Amber Lens -- Lens choices that support crisp white output or added contrast in dust, fog, rain, and mixed conditions.
• Black or White Housing -- Housing choices that help the flush mount light match surrounding trim, panel color, or Baja Designs styling preferences.

Choose Sport for efficient compact output, choose Pro for more intensity, choose a focused beam for driving visibility, or choose Work/Scene when broad area lighting matters most.



---



Why Choose

This product is ideal for customers who want low-profile auxiliary lighting with Baja Designs output, beam control, and a clean integrated appearance.

• Flush mount design helps customers build a cleaner lighting package with less exposed hardware.
• Multiple beam options make the pod useful for driving, cornering, work, reverse, and scene-lighting roles.
• Output choices help balance power draw, brightness, and application needs.
• Lens color options make it easier to tailor visibility for weather, dust, and terrain conditions.
• Compact dimensions simplify placement in custom panels and tight bumper areas when clearance is available.
• Updated serviceable components support future lens service and long-term use.
• Baja Designs styling gives the finished installation a premium off-road lighting appearance.



---



What's Included

• One Squadron 2.0 Sport or Pro flush mount LED auxiliary light pod, depending on selected configuration
• Flush mount hardware for the selected light pod
• Selected lens color and beam pattern
• Installation information for the selected configuration

Note: Confirm included components before installation.



---



Installation Notes

• Confirm panel depth, wiring clearance, and mounting surface strength before cutting or drilling.
• Flush mount installation may require trimming or fabrication depending on the mounting location.
• Wiring harnesses, switches, and additional brackets may vary by selected configuration or installation plan.
• Aim and test the light after installation to confirm beam placement and clearance.

Buyer is responsible for use in accordance with applicable vehicle, road, off-road, towing, racing, and local laws.



---



Warranty Information

Baja Designs lighting products are backed by warranty support that is intended to protect against qualifying defects in materials or workmanship. Warranty coverage typically requires proof of purchase and may depend on inspection of the product and the installation conditions.

Warranty coverage typically excludes improper installation, misuse, modifications, electrical issues, overloading, tampering, impact damage outside warranty terms, or non-compliant use. Customers should retain purchase records and follow the supplied installation information for the selected application.
